Khoom Taw Qhia
A918 activated alumina catalyst ntawm sulfur rov qab yog ib qho khoom siv hluavtaws ua haujlwm Al2O3catalyst, uas muaj kev ua tau zoo ntawm cov tshuaj tiv thaiv -sulfated tshuaj lom, ntau dua hydrolysis muaj nuj nqi ntawm cov organic sulfur compounds thiab tus cwj pwm zoo ntawm cov cua sov tsis tu ncua.
Cov txiaj ntsig ntawm kev sim ua haujlwm tau ua pov thawj tias A918 activated alumina catalyst muaj qhov zoo ntawm kev ua haujlwm siab thiab tuav lub zog, uas tuaj yeem siv rau 3 ~ 5 xyoos tsis tu ncua.
Piv nrog rau bauxite, tag nrho cov txiaj ntsig ntawm leej faj rov qab tuaj yeem nce los ntawm 80 ~ 85% mus rau 94 ~ 96% hauv cov txheej txheem sib npaug lossis zoo sib xws. Lub hydrolysis ntawm COS tau mus txog 100% thiab cov sulfur tus nqi ntawm tus Tsov tus tw roj tau txo qis hauv qab mus rau 1%.
Txhua yam khoom ntawm A918 activated alumina catalyst, uas nws qhov chaw tshwj xeeb tau ncav cuag 320m2/g, tau mus txog qib siab hauv ntiaj teb.
Khoom Parameters
Mahauv technical indexesA918 activated alumina catalyst
|
Kev lag luam- cov yam ntxwv tshwj xeeb |
|
|
Lwm yam cwj pwm |
|
|
Qhov Chaw Keeb Kwm |
Tuam Tshoj |
|
Kev faib tawm |
Catalyst |
|
Lwm Lub Npe |
Claus Catalyst |
|
Daim ntawv thov |
Sulfur Recovery for Claus Process |
|
Hom Lub Npe |
XUNDA |
|
Qauv nab npawb |
A918 Activated Alumina Catalyst |
|
Main technical indexes |
|
|
Cov Khoom Siv Tseem Ceeb |
Al2O3 |
|
Qhov tshwm sim |
Dawb thiab sphere los yog granule |
|
Al2O3,% |
Ntau tshaj 93 |
|
Loj, mm |
φ4-6 |
|
Ib cheeb tsam tshwj xeeb, m2/g |
Ntau dua lossis sib npaug li 300 |
|
Qhov hnyav, kg / L |
0.6-0.8 |
|
Nruab Nrab Crushing Strength, N / nplej |
Ntau dua lossis sib npaug li 130 |
|
Kev puas tsuaj,% (m / m) |
Tsawg dua los yog sib npaug li 1 |
|
Qhov hnyav, ml / g |
Ntau dua lossis sib npaug li 0.4 |
|
Static Water Absorption |
50~70% |
|
Muaj peev xwm muab khoom |
|
|
Chaw tsim khoom |
Yog lawm |
|
Daim ntawv pov thawj |
ISO9001: 2015 |
|
Muaj peev xwm muab khoom |
9500 Tons / ib xyoos |
|
Ntim thiab xa khoom |
|
|
Ntim Cov Lus Qhia |
Jumbo hnab los yog steel nruas pob los yog cardboard thoob |
|
Chaw nres nkoj |
Shanghai, Ningbo, Shenzhen, Qingdao |
|
Muag Khoom |
Ib yam khoom |
|
MOQ |
1 ton |
Mahauv technical indexesua a918 Activated Alumina Catalyst
|
Lub Sijhawm Lead |
||
|
Qhov hnyav (kg) |
1-1000 |
>1000 |
|
Lub sij hawm xa tuaj (hnub) |
15 |
Yuav tsum sib tham |
Daim ntawv thov
Cov txheej txheem Claus yog siv los ntawm kev lag luam sulfur rov qab uas hloov hydrogen sulfide rau hauv cov tshuaj sulfur thiab dej. Cov roj av "qaub" muaj ntau cov hydrogen sulfide nyob rau hauv thiab yog tias cov roj no raug hlawv ua roj, sulfide khiav tawm, ua rau huab cua muaj kuab lom thiab puas tsuaj rau peb ib puag ncig kev sib tw. Nws tau dhau los ua ib qho kev xav tau ntawm tib neeg los hloov siab tshaj plaws ntawm leej faj los ntawm "kua" roj.
Al2O3activated alumina catalyst yog feem ntau siv raws li Claus catalyst uas muaj ntau tus catalytic active nto qhov chaw uas absorbs Hydrogen Sulfide (H2S) thiab sulfur Dioxide (SO2) rau cov tshuaj tiv thaiv tom ntej rau yield elemental sulfur.
Nyob rau hauv ntau cov kua qaub gas, leej faj muaj nyob rau hauv ntau lub tebchaw xws li H2S, COS, CS2, thiab lwm yam. Ib txhia ntawm lawv tej zaum yuav tsis muaj nyob rau hauv cov pa roj, tab sis cubustion ntawm H2S nyob rau hauv lub xub ntiag ntawm CO2los yog hydrocarbons tuaj yeem ua rau tsim COS / CS2. Cov tebchaw no yuav tsum tau hloov dua siab tshiab kom ntseeg tau tias kev hloov pauv ntawm leej faj. Txij li thaum lub decomposition tus nqi ntawm cov tebchaw yog qis dua tus nqi ntawm H2S/SO2cov tshuaj tiv thaiv, yuav tsum muaj cov catalyst heev. Sulfation tuaj yeem yog lwm qhov teeb meem vim nws txo qhov chaw saum npoo thiab yog li, qhov deactivation ntawm catalyst.
Peb cov kev ua tau zoo Sulfur Recovery Activated Alumina Catalyst yog qhov zoo tagnrho rau Claus units hauv cov nroj tsuag roj, roj refineries, coke nroj tsuag, tail gas units, thiab lwm yam.
Daim ntawv thov
Peb lub Hoobkas
Factory Gate View
Tag nrho cov khoom siv tsis siv neeg ua ke
Cov kab ntau lawm niaj hnub
Cov txheej txheem tsim khoom
